Terminal tube Ring terminal Cable lug
Ring terminal 090001
Part no.: |
090001 |
Type: | Pipe cable lug |
Cable size: | 4 – 6 mm² |
Hole size: | 6.4 mm |
Bolt size: | M6 |
Material: | Copper, tin-plated |
Description: |  Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090002
Part no.: |
090002 |
Type: | Pipe cable lug |
Cable size: | 4 – 6 mm² |
Hole size: | 8.4 mm |
Bolt size: | M8 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090003
Part no.: |
090003 |
Type: | Pipe cable lug |
Cable size: | 6 – 10 mm² |
Hole size: | 6.4 mm |
Bolt size: | M6 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090004
Part no.: |
090004 |
Type: | Pipe cable lug |
Cable size: | 6 – 10 mm² |
Hole size: | 8.4 mm |
Bolt size: | M8 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090005
Part no.: |
090005 |
Type: | Pipe cable lug |
Cable size: | 6 – 10 mm² |
Hole size: | 10.5 mm |
Bolt size: | M10 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090006
Part no.: |
090006 |
Type: | Pipe cable lug |
Cable size: | 10 – 16 mm² |
Hole size: | 6.4 mm |
Bolt size: | M6 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090007
Part no.: |
090007 |
Type: | Pipe cable lug |
Cable size: | 10 – 16 mm² |
Hole size: | 8.4 mm |
Bolt size: | M8 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090008
Part no.: |
090008 |
Type: | Pipe cable lug |
Cable size: | 10 – 16 mm² |
Hole size: | 10.5 mm |
Bolt size: | M10 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090009
Part no.: |
090009 |
Type: | Pipe cable lug |
Cable size: | 16 – 25 mm² |
Hole size: | 6.4 mm |
Bolt size: | M6 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090010
Part no.: |
090010 |
Type: | Pipe cable lug |
Cable size: | 16 – 25 mm² |
Hole size: | 8.4 mm |
Bolt size: | M8 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090011
Part no.: |
090011 |
Type: | Pipe cable lug |
Cable size: | 16 – 25 mm² |
Hole size: | 10.5 mm |
Bolt size: | M10 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090021
Part no.: |
090021 |
Type: | Pipe cable lug |
Cable size: | 25 – 35 mm² |
Hole size: | 6.4 mm |
Bolt size: | M6 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Terminal tube Ring terminal Cable lug
Ring terminal 090012
Part no.: |
090012 |
Type: | Pipe cable lug |
Cable size: | 25 – 35 mm² |
Hole size: | 8.4 mm |
Bolt size: | M8 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090013
Part no.: |
090013 |
Type: | Pipe cable lug |
Cable size: | 25 – 35 mm² |
Hole size: | 10.5 mm |
Bolt size: | M10 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090014
Part no.: |
090014 |
Type: | Pipe cable lug |
Cable size: | 25 – 35 mm² |
Hole size: | 13.0 mm |
Bolt size: | M12 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090015
Part no.: |
090015 |
Type: | Pipe cable lug |
Cable size: | 35 – 50 mm² |
Hole size: | 8.4 mm |
Bolt size: | M8 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090016
Part no.: |
090016 |
Type: | Pipe cable lug |
Cable size: | 35 – 50 mm² |
Hole size: | 10.5 mm |
Bolt size: | M10 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090017
Part no.: |
090017 |
Type: | Pipe cable lug |
Cable size: | 35 – 50 mm² |
Hole size: | 13.0 mm |
Bolt size: | M12 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090022
Part no.: |
090022 |
Type: | Pipe cable lug |
Cable size: | 50 – 70 mm² |
Hole size: | 6.4 mm |
Bolt size: | M6 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090018
Part no.: |
090018 |
Type: | Pipe cable lug |
Cable size: | 50 – 70 mm² |
Hole size: | 8.4 mm |
Bolt size: | M8 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090019
Part no.: |
090019 |
Type: | Pipe cable lug |
Cable size: | 50 – 70 mm² |
Hole size: | 10.5 mm |
Bolt size: | M10 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090020
Part no.: |
090020 |
Type: | Pipe cable lug |
Cable size: | 50 – 70 mm² |
Hole size: | 13.0 mm |
Bolt size: | M12 |
Material: | Copper, tin-plated |
Description: | Inspection hole to visually assure full conductor insertion. |
Ring terminal 090116
Part no.: |
090116 |
Type: | Angle cable lug |
Angle: | 90° |
Cable size: | 10 – 50 mm² |
Hole size: | 10.5 mm |
Bolt size: | M10 |
Material: | Copper, tin-plated |
Description: | No Inspection hole |
